Kubota LX2620SUHSD
Request a quote
Tell us what you need it for and we will come back with the options that matter.
LX2620SUHSD key specs
| Engine power | 23.3 hp (17.4 kW) |
|---|---|
| PTO power | 19.4 hp (14.5 kW) |
| Transmission | HST (3 ranges) |
| 3-point lift, 24 in (610 mm) behind | 1,676 lb (760 kg) |
| Weight | 1,775 lb (805 kg) |
About the LX2620SUHSD
LX2620SUHSD specifications
Engine16
| Engine type | Indirect Injection, Vertical, water cooled 3 cylinder diesel engine |
|---|---|
| Engine model | D1305-E4-D36R |
| PTO power | 19.4 hp (14.5 kW) |
| Engine power, gross | 23.3 hp (17.4 kW) |
| Rated engine speed | 2,500 rpm |
| Bore | 3.1 in (78 mm) |
| Stroke | 3.5 in (88 mm) |
| Displacement | 1,261 cc (77 cu in) |
| Air pre-cleaner | 4.5 inch Paper filter with (dual element) |
| Lubrication | Forced lubrication |
| Cooling system | Pressurized radiator |
| Radiator fan | Radial air flow |
| Fuel tank | 27 L (7.1 US gal) |
| Cooling system capacity | 4.3 L (4.5 US qt) |
| Engine lubricant oil capacity | 4 L (4.2 US qt) |
| Transmission oil capacity | 15 L (4 US gal) |
PTO3
| PTO type | Independent |
|---|---|
| Rear, PTO/engine speed | 540 rpm |
| Mid, rated engine speed | 2,500 rpm |
Transmission and drive7
| Clutch | N / A |
|---|---|
| Transmission | HST (3 ranges) |
| Differential lock | Standard |
| Brakes | Multi-plate wet disc |
| Final drive | Spur gear |
| Forward (R1) | 18 km/h (11.2 mph) |
| Reverse (R1) | 13.5 km/h (8.4 mph) |
Hydraulics9
| Hydraulic system | Open center |
|---|---|
| Pump type | Dual pump |
| Total pump output | 8.7 US gpm (33.1 L/min) |
| Hydraulic outlet | Rear outlet |
| 3-point hitch | Category I |
| Control system | Position control |
| Steering | Hydraulic power steering |
| 3-point lift capacity, at the lift points | 2,139 lb (970 kg) |
| 3-point lift capacity, 24 in (610 mm) behind the lift points | 1,676 lb (760 kg) |
Dimensions and weight13
| Standard tire size, front R1 | 7-12 |
|---|---|
| Standard tire size, front R4 | 23x8.50-14 |
| Standard tire size, front R14 | 23x8.50-12 |
| Standard tire size, rear R1 | 12.4-16 |
| Standard tire size, rear R4 | 12.4-16 |
| Standard tire size, rear R14 | 14-17.5 |
| Overall length, without the 3-point hitch | 101.8 in (2,586 mm) |
| Overall width, at the narrowest tread | 53.7 in (1,365 mm) |
| Overall height | 88.4 in (2,245 mm) |
| Wheelbase | 65.6 in (1,666 mm) |
| Ground clearance | 14.6 in (370 mm) |
| Weight | 1,775 lb (805 kg) |
| Turning radius, with brake | 6.9 ft (2.1 m) |
From Kubota Canada’s specifications for the LX2620SUHSD, read Oct 24, 2026. Options and attachments change some figures; ask us before you buy.
The LX20 series
LX2620HSD
- 23.3 hp
- 19.4 hp PTO
- 1,676 lb lift at 24 in

LX2620HSDCC
- 23.3 hp
- 19.4 hp PTO
- 1,676 lb lift at 24 in
LX2620SUHSD
- 23.3 hp
- 19.4 hp PTO
- 1,676 lb lift at 24 in

LX3520HSDCC
- 34.9 hp
- 28.7 hp PTO
- 1,962 lb lift at 24 in

LX3520HSDRC
- 34.9 hp
- 28.7 hp PTO
- 1,962 lb lift at 24 in

LX4020HSDCC
- 39.8 hp
- 31.2 hp PTO
- 1,962 lb lift at 24 in

LX4020HSDRC
- 39.8 hp
- 32.6 hp PTO
- 1,962 lb lift at 24 in
Implements matched to the LX2620SUHSD
Kubota's matched-implement brochures and Land Pride's Kubota charts pair these implements with the LX2620SUHSD. Each one is rated for the LX2620SUHSD's horsepower and 3-point hitch.
-
New
Land Pride BB1272 Box Scraper
The BB1272 is Land Pride's 72-inch box scraper for compact tractors of 17 to 30 hp, on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Six heat-treated spring-steel shanks with replaceable dimpled-on tips rip hard ground and lift by hand t...
View unitQuote
-
New
Land Pride QH16 Quick Hitch
The QH16 is Land Pride's quick hitch for tractors with a Category I 3-point hitch: it lets you hook on to an implement, often without leaving the seat, and its locks close on the implement's lower pins by themselves. The top hook adjusts from 14-7/8 to 18-7...
View unitQuote
-
NewClearance
Land Pride RB1560 Rear Blade
The RB1560 is Land Pride's 60-inch rear blade for tractors of 17 to 40 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 14-inch moldboard angles forward up to 45 degrees in seven positions and backward up to 30 degrees, either way, and o...
View unitQuote
-
NewClearance
Land Pride RB1684 Rear Blade
The RB1684 is Land Pride's 84-inch rear blade for tractors of 20 to 40 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 14-inch moldboard angles forward up to 45 degrees in seven positions and backward up to 30 degrees, offsets 12 inches...
View unitQuote
-
NewClearance
Land Pride RCR1248 Rotary Cutter
The RCR1248 is Land Pride's 48-inch rotary cutter for subcompact and compact tractors of 20 to 60 hp, on a Category I hitch that is quick-hitch ready. It cuts grass, weeds and light brush at heights from 1-1/4 to 10 inches with two free-swinging heat-treate...
View unitQuote
-
NewClearance
Land Pride RCR1260 Rotary Cutter
The RCR1260 is Land Pride's 60-inch rotary cutter for compact tractors of 20 to 60 hp, on a Category I hitch that is quick-hitch ready. It cuts grass, weeds and light brush at heights from 1-1/4 to 10 inches with two free-swinging heat-treated blades, drive...
View unitQuote
-
NewClearance
Land Pride RTR0550 Rotary Tiller
The RTR0550 is Land Pride's 50-inch reverse-rotation rotary tiller for subcompact tractors of up to 26 PTO hp, on a Category I hitch, and it fits Land Pride's Category I Quick Hitch. Seven flanges of four heat-treated C-shaped tines turn at 230 rpm against ...
View unitQuote
-
NewClearance
Land Pride RTR1250 Rotary Tiller
The RTR1250 is Land Pride's 50-inch reverse-rotation rotary tiller for compact tractors of 15 to 40 PTO hp, on a Category I hitch with adjustable lower clevises, and it fits Land Pride's Quick Hitch, where it must sit centred and may need a longer driveline...
View unitQuote
-
NewClearance
Land Pride PD15 Post Hole Digger
The PD15 is a 3-point post hole digger for compact tractors of 20 to 40 hp with a Category I hitch. It runs 48-inch dirt augers in 6, 9 and 12 inch diameters, takes rock augers from 6 to 18 inches, and its Category II driveline carries a shear bolt that pro...
View unitQuote
-
New
Land Pride BB1248 Box Scraper
The BB1248 is Land Pride's 48-inch box scraper for compact tractors of 17 to 30 hp, on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Four heat-treated spring-steel shanks with replaceable dimpled-on tips rip hard ground and lift by hand ...
Get pricingQuote
-
New
Land Pride BB1260 Box Scraper
The BB1260 is Land Pride's 60-inch box scraper for compact tractors of 17 to 30 hp, on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Four heat-treated spring-steel shanks with replaceable dimpled-on tips rip hard ground and lift by hand ...
Get pricingQuote
-
New
Land Pride FSP700 Broadcast Spreader
The FSP700 is Land Pride's 3-point broadcast spreader for tractors of 18 hp and up, on a Category I hitch. Its one-piece polyethylene hopper holds about 9 cubic feet, up to 563 lb, and a spinner driven from the 540 rpm PTO spreads granular material 23 to 54...
Get pricingQuote
-
New
Land Pride FSP1000 Broadcast Spreader
The FSP1000 is Land Pride's largest 3-point broadcast spreader, for tractors of 20 hp and up, on a Category I hitch. Its one-piece polyethylene hopper holds about 12 cubic feet, up to 673 lb, and a spinner driven from the 540 rpm PTO spreads granular materi...
Get pricingQuote
-
New
Land Pride RB0560 Rear Blade
The RB0560 is Land Pride's 60-inch rear blade for tractors of 17 to 25 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 13-1/2-inch moldboard angles up to 30 degrees either way, forward or back, in five positions each, and offsets 10 inc...
Get pricingQuote
-
New
Land Pride RB1672 Rear Blade
The RB1672 is Land Pride's 72-inch rear blade for tractors of 20 to 40 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 14-inch moldboard angles forward up to 45 degrees in seven positions and backward up to 30 degrees, offsets 12 inches...
Get pricingQuote
More implements matched to the LX Series are in Kubota's brochure. Kubota's LX Series matched-implement brochure (PDF) ↗
