Compact Track LoadersNew
Kubota SVL110-3 Compact Track Loader
Representative photo of this model, not the machine on the yard.
Request a quote
Tell us what you need it for and we will come back with the options that matter.
One in stock in Sexsmith. 3 on order, arriving March 2027.
Key specs
SVL110-3 key specs
| Rated operating capacity | 1,678 kg (3,700 lb), 35% of tipping load |
|---|---|
| Engine power | 112.7 hp (84 kW) |
| Operating weight | 5,589 kg (12,322 lb), with a 75 kg (165 lb) operator |
| Hinge-pin height | 3,264 mm (128.5 in) |
| Auxiliary flow | 170.4 L/min (45 US gpm), high flow |
About this model
About the SVL110-3
Available through Grande Prairie Kubota in Sexsmith. The SVL110-3 is the machine we spec for contractors running mulchers and cold planers, where the 45 GPM high-flow circuit is the deciding factor. Cab, heat and air recommended for year-round work in the Peace.
Powerful where it counts most.
At Kubota, we're never satisfied. The SVL110-3 compact track loader builds on the proven reliability of the SVL97-3, retaining its compact size while delivering substantially more power. Equipped with 112.7 gross HP and 45 GPM auxiliary flow, plus advanced features like Creep Mode, it handles asphalt work, site prep, forest clearing, and heavy attachment work with ease. We've enhanced operator comfort, simplified maintenance, and engineered the strength you need to fully leverage high-flow attachments. Built for contractors who demand performance without compromise.
Powerful where it counts most.
At Kubota, we're never satisfied. The SVL110-3 compact track loader builds on the proven reliability of the SVL97-3, retaining its compact size while delivering substantially more power. Equipped with 112.7 gross HP and 45 GPM auxiliary flow, plus advanced features like Creep Mode, it handles asphalt work, site prep, forest clearing, and heavy attachment work with ease. We've enhanced operator comfort, simplified maintenance, and engineered the strength you need to fully leverage high-flow attachments. Built for contractors who demand performance without compromise.
Specifications
SVL110-3 specifications
Engine11
| Engine model | V3800-TIE5-LA |
|---|---|
| Engine power, gross | 112.7 hp (84 kW) |
| Engine power, net | 101.3 hp (75.6 kW) |
| Rated engine speed | 2,500 rpm |
| Displacement | 3,769 cc (230 cu in) |
| Cylinders | 4 |
| Bore | 100 mm (3.9 in) |
| Stroke | 120 mm (4.7 in) |
| Aspiration | Turbocharged |
| Fuel tank | 115.7 L (30.6 US gal) |
| DEF tank | 12.7 L (3.4 US gal) |
Travel5
| Ground contact pressure, standard | 0.34 kg/cm² (4.8 psi) |
|---|---|
| Track rollers (per side) | 5 |
| Maximum traction force | 5,976 kgf (13,174.7 lbf) |
| Travel speed, low | 8.8 km/h (5.5 mph) |
| Travel speed, high | 13.4 km/h (8.4 mph) |
Hydraulics4
| Auxiliary hydraulic flow, high | 170.4 L/min (45 US gpm) |
|---|---|
| Auxiliary hydraulic pressure | 250 kg/cm² (3,553 psi) |
| Hydraulic tank | 40.2 L (10.6 US gal) |
| Hydraulic system capacity | 70.1 L (18.5 US gal) |
Loader and lift6
| Rated operating capacity (SAE), 35% of tipping load | 1,678 kg (3,700 lb) |
|---|---|
| Rated operating capacity (SAE), 50% of tipping load | 2,398 kg (5,286 lb) |
| Tipping load, straight | 4,795 kg (10,571 lb) |
| Lift arm path | Vertical |
| Breakout force, bucket | 3,469 kgf (7,650 lbf) |
| Breakout force, lift arm | 2,398 kgf (5,288 lbf) |
Dimensions and weight5
| Ground clearance | 278 mm (10.9 in) |
|---|---|
| Operating weight | 5,589 kg (12,322 lb), with a 75 kg (165 lb) operator |
| Track width, standard | 450 mm (17.7 in) |
| Undercarriage, length of track on ground | 1,667 mm (65.6 in) |
| Bucket hinge pin height at maximum lift | 3,264 mm (128.5 in) |
Operator station and other1
| Operator station | Closed cab |
|---|
From Kubota Canada’s specifications for the SVL110-3, read Oct 27, 2026. Options and attachments change some figures; ask us before you buy.
Compare
Track loaders near this size
This row shows the two track loaders on our site next below it in engine power; none of ours is more powerful.
SVL75-3 Compact Track Loader
- 1,129 kg rated capacity
- 71.6 hp
SVL97-3 Compact Track Loader
- 1,569 kg rated capacity
- 96.4 hp
This model
SVL110-3 Compact Track Loader
- 1,678 kg rated capacity
- 112.7 hp
