Kubota BX2690
The 23.9 gross hp top of Kubota's BX90 sub-compact series: a 3-cylinder diesel, standard 4WD, and a build tested in Canada down to −35 °C for snow, mud and rough ground. Offered in Standard, Deluxe and Premium trims.
Representative photo of this model.
Request a quote
Tell us what you need it for and we will come back with the options that matter.
BX2690 key specs
| Engine power | 23.9 hp (17.8 kW) |
|---|---|
| PTO power | 18.7 hp (13.9 kW) |
| Transmission | 2-range HST, High-Low gear shift |
| 3-point lift, 24 in (610 mm) behind | 898 lb (407 kg) |
| Weight | 1,477 lb (670 kg) |
About the BX2690
Powered by durable Kubota 3-cylinder diesel engines ranging from 19.3 to 23.9 HP, the BX90 Series delivers the dependable performance needed for demanding property work. Premium models add an electronically controlled engine for smoother response, improved efficiency, a broader torque curve under load, and added convenience features like temporary throttle up on the joystick.
Kubota’s K-Connect front hitch and PTO system makes it quick and easy to install and remove front attachments like a snowblower, blade, or rotary sweeper. By keeping the attachment out front, K-Connect improves sightlines and operator comfort while helping the BX90 stay productive year-round.
BX2690 specifications
Engine10
| Engine model | D902-K |
|---|---|
| Engine type | Electronically controlled indirect injection, 4 cycle diesel |
| Cooling system | Liquid-cooled |
| Rated engine speed | 3,600 rpm |
| Engine power, gross | 23.9 hp (17.8 kW) |
| PTO power | 18.7 hp (13.9 kW) |
| Displacement | 898 cc (54.8 cu in) |
| Fuel tank | 25 L (6.6 US gal) |
| Cylinders | 3 |
| Headlights | LED with Signature |
PTO5
| Mid-PTO | Standard |
|---|---|
| Rear PTO speed | Standard |
| PTO type | Electric Live independent PTO (With hydraulic clutch) |
| Rear, PTO/engine speed | 540 rpm |
| Mid, rated engine speed | 2,651 rpm |
Transmission and drive6
| Transmission | 2-range HST, High-Low gear shift |
|---|---|
| Brakes | Wet disc |
| Drive | 4WD |
| Cruise control | Standard |
| At rated engine rpm (turf), forward | 14.3 km/h (8.9 mph) |
| At rated engine rpm (turf), reverse | 11.1 km/h (6.9 mph) |
Hydraulics8
| 3-point hitch | Category I |
|---|---|
| Stabilizers | Telescopic |
| Loader valve | Standard |
| Total pump output | 7.7 US gpm (29 L/min) |
| Steering | Hydrostatic Power Steering |
| 3-point hitch, type | Position |
| 3-point lift capacity, 24 in (610 mm) behind the lift points | 898 lb (407 kg) |
| Rear remote valves | 2 |
Dimensions and weight13
| Tires, front | 18x8.5-10 |
|---|---|
| Tires, rear | 26x12-12 |
| Tire type, front | Turf (R3), Industrial (R4), Hybrid (R14) |
| Tire type, rear | Turf (R3), Industrial (R4), Hybrid (R14) |
| Ground clearance | 8.4 in (213 mm) |
| Overall width | 44.5 in (1,130 mm) |
| Wheelbase | 55.1 in (1,400 mm) |
| Overall height | 82.3 in (2,090 mm) |
| Turning radius | 90 in (2.3 m) |
| Weight | 1,477 lb (670 kg) |
| Overall length, with 3 pt hitch | 95.5 in (2,425 mm) |
| Tread width, front | 36.6 in (930 mm) |
| Tread width, rear | 34.3 in (870 mm) |
Operator station and other2
| Trim level | Premium |
|---|---|
| Tilt steering wheel | Standard |
From Kubota Canada’s specifications for the BX2690, read Oct 24, 2026. Options and attachments change some figures; ask us before you buy.
The BX90 series

BX2190
- 19.3 hp
- 15.7 hp PTO
- 950 lb lift at 24 in

BX2390
- 21.6 hp
- 17.2 hp PTO
- 892 lb lift at 24 in

BX2390S
- 21.6 hp
- 17.6 hp PTO
- 950 lb lift at 24 in

BX2690
- 23.9 hp
- 18.7 hp PTO
- 898 lb lift at 24 in

BX2690S
- 23.9 hp
- 18.7 hp PTO
- 898 lb lift at 24 in
Implements matched to the BX2690
Kubota's matched-implement brochures and Land Pride's Kubota charts pair these implements with the BX2690. Each one is rated for the BX2690's horsepower and 3-point hitch.
-
New
Land Pride BB1272 Box Scraper
The BB1272 is Land Pride's 72-inch box scraper for compact tractors of 17 to 30 hp, on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Six heat-treated spring-steel shanks with replaceable dimpled-on tips rip hard ground and lift by hand t...
View unitQuote
-
New
Land Pride QH16 Quick Hitch
The QH16 is Land Pride's quick hitch for tractors with a Category I 3-point hitch: it lets you hook on to an implement, often without leaving the seat, and its locks close on the implement's lower pins by themselves. The top hook adjusts from 14-7/8 to 18-7...
View unitQuote
-
NewClearance
Land Pride RB1560 Rear Blade
The RB1560 is Land Pride's 60-inch rear blade for tractors of 17 to 40 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 14-inch moldboard angles forward up to 45 degrees in seven positions and backward up to 30 degrees, either way, and o...
View unitQuote
-
NewClearance
Land Pride RCR1248 Rotary Cutter
The RCR1248 is Land Pride's 48-inch rotary cutter for subcompact and compact tractors of 20 to 60 hp, on a Category I hitch that is quick-hitch ready. It cuts grass, weeds and light brush at heights from 1-1/4 to 10 inches with two free-swinging heat-treate...
View unitQuote
-
NewClearance
Land Pride RTR0550 Rotary Tiller
The RTR0550 is Land Pride's 50-inch reverse-rotation rotary tiller for subcompact tractors of up to 26 PTO hp, on a Category I hitch, and it fits Land Pride's Category I Quick Hitch. Seven flanges of four heat-treated C-shaped tines turn at 230 rpm against ...
View unitQuote
-
NewClearance
Land Pride RTR1250 Rotary Tiller
The RTR1250 is Land Pride's 50-inch reverse-rotation rotary tiller for compact tractors of 15 to 40 PTO hp, on a Category I hitch with adjustable lower clevises, and it fits Land Pride's Quick Hitch, where it must sit centred and may need a longer driveline...
View unitQuote
-
NewClearance
Land Pride LR1672 Landscape Rake
The LR1672 is a 72-inch landscape rake for compact tractors of 20 to 40 hp on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Its 36 high-carbon spring-steel teeth sit on 2-inch centres and can be replaced one at a time, and the rake angle...
View unitQuote
-
New
Land Pride BB1248 Box Scraper
The BB1248 is Land Pride's 48-inch box scraper for compact tractors of 17 to 30 hp, on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Four heat-treated spring-steel shanks with replaceable dimpled-on tips rip hard ground and lift by hand ...
Get pricingQuote
-
New
Land Pride BB1260 Box Scraper
The BB1260 is Land Pride's 60-inch box scraper for compact tractors of 17 to 30 hp, on a Category I 3-point hitch, and it fits Land Pride's Quick Hitch. Four heat-treated spring-steel shanks with replaceable dimpled-on tips rip hard ground and lift by hand ...
Get pricingQuote
-
New
Land Pride QH05 Quick Hitch
The QH05 is Land Pride's quick hitch for subcompact tractors with a Category I 3-point hitch: it lets you hook on to an implement, often without leaving the seat, and its locks close on the implement's lower pins by themselves. It fits Category I pins witho...
Get pricingQuote
-
New
Land Pride RB0560 Rear Blade
The RB0560 is Land Pride's 60-inch rear blade for tractors of 17 to 25 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 13-1/2-inch moldboard angles up to 30 degrees either way, forward or back, in five positions each, and offsets 10 inc...
Get pricingQuote
-
New
Land Pride RB1672 Rear Blade
The RB1672 is Land Pride's 72-inch rear blade for tractors of 20 to 40 hp, on a Category I hitch, and it fits Land Pride's Quick Hitch. The 14-inch moldboard angles forward up to 45 degrees in seven positions and backward up to 30 degrees, offsets 12 inches...
Get pricingQuote
