TractorsNew
Kubota M7-174D-PS
Representative photo of this model.
Request a quote
Tell us what you need it for and we will come back with the options that matter.
None on the yard right now. 1 on order, arriving November 2026.
Key specs
M7-174D-PS key specs
| Engine power | 168 hp (125.3 kW) |
|---|---|
| PTO power | 140 hp (104.4 kW) |
| Transmission | Semi-Powershift; 30 forward, 15 reverse |
| 3-point lift, 610 mm (24 in) behind | 5,350 kg (11,797 lb), OECD |
| Weight | 6,598 kg (14,546 lb), shipping |
About this model
About the M7-174D-PS
Introducing a new generation of the M7 series, the simple and reliable Kubota M7-4. You talked, we listened: the M7 series brings a variety of new features for greater productivity and operator comfort. Expect Kubota power and the capability needed for big jobs with major performance from 168 gross horsepower.
Specifications
M7-174D-PS specifications
Engine15
| Engine model | V6108-CR-TIER4 |
|---|---|
| Engine type | Direct Injection, with Intercooler turbocharger, water-cooled 4 cycle diesel engine |
| Displacement | 6,124 cc (374 cu in) |
| Bore | 118 mm (4.65 in) |
| Stroke | 140 mm (5.5 in) |
| Rated engine speed | 2,100 rpm |
| Engine power, gross | 168 hp (125.3 kW) |
| Boost power | 5 hp |
| PTO power | 140 hp (104.4 kW) |
| Alternator | 200 A |
| Fuel tank | 330 L (87 US gal) |
| Cylinders | 4 |
| Fuel | Diesel |
| Battery | 174 amp-hours; 1,400 A |
| DEF tank | 38 L (10 US gal) |
PTO2
| Rear, PTO/engine speed | 540 rpm |
|---|---|
| Front, PTO/engine speed | 1,000 rpm |
Transmission and drive11
| Transmission | Semi-Powershift |
|---|---|
| Main gears | 6-speed Powershift |
| Range gears | 5-speed synchronized (GST) |
| Top speed | 40 km/h (25 mph) |
| Shuttle | Electro-hydraulic shuttle |
| Number of speeds, forward | 30 |
| Number of speeds, reverse | 15 |
| Number of speeds (optional), creep (forward) | 54 |
| Number of speeds (optional), creep (reverse) | 27 |
| Clutch type, main clutch | Hydraulic multi-plate wet disc |
| Rear axle type | Flanged axle or 110" bar axle |
Hydraulics6
| Hydraulic system | Closed center, load sensing |
|---|---|
| Pump flow | 110 L/min (29 US gpm) |
| 3-point hitch | Category 3 / 3N |
| Control system | Electronic draft control / Lower link sensing |
| Remote valves | Up to 4, mechanical |
| 3-point lift capacity, 610 mm (24 in) behind the lift points (OECD) | 5,350 kg (11,797 lb) |
Dimensions and weight7
| Tires, standard, front | 14.9 R28 |
|---|---|
| Tires, standard, rear | 18.4 R38 |
| Overall length | 4,770 mm (188 in) |
| Overall height | 3,030 mm (119 in) |
| Overall width | 2,500 mm (98.4 in) |
| Wheelbase | 2,720 mm (107 in) |
| Shipping weight | 6,598 kg (14,546 lb) |
From Kubota Canada’s specifications for the M7-174D-PS, read Oct 24, 2026. Options and attachments change some figures; ask us before you buy.
Compare
The M7-4 series
M7-134D-PS
- 128 hp
- 100 hp PTO
- 5,350 kg lift at 24 in
M7-134P-KVT
- 128 hp
- 100 hp PTO
- 5,350 kg lift at 24 in
M7-154D-PS
- 148 hp
- 120 hp PTO
- 5,350 kg lift at 24 in
M7-154P-KVT
- 148 hp
- 120 hp PTO
- 5,350 kg lift at 24 in
This model
M7-174D-PS
- 168 hp
- 140 hp PTO
- 5,350 kg lift at 24 in
M7-174P-KVT
- 168 hp
- 140 hp PTO
- 5,350 kg lift at 24 in
